Egypt Overflight Permit Regulations

Delivery Aircraft Trip Support
Egypt Overflight Permits Procedures

International Trip Planning


Egypt country has its own set of rules, regulations and procedures for permits to aircraft wishing for landing or even entering their air space, whether you’re operating a private flight or general aviation, charter flight, scheduled or non-scheduled operation, passengers or cargo trip, a technical or traffic landing, Prior Permission is mandatory required the application procedures requiring complete flight information and Aircraft documents.

According to egypt civil aviation authority aeronautical information publication (or AIP) any aircraft owner/operator intent to fly in Egypt airspace request has to submit for Egypt overflight clearance to air transport department at least 48 working hours prior from flight departure schedule. Always include AFTN on your flight plan, but you’ll only need an overfly permit from Egypt.

Planning to make a passenger flight landing or technical stop, Egypt Airports Authority have their own regulations regarding the issuance of flight Egypt Overflight permit as there is generally a payment involved. The charges normally payable would be the Route Navigation Facility Charges for overflight and also landing and parking charges in case of aircraft making halts.

Egypt is a signatory to the Chicago Convention therefore the conditions of flights and crews should strictly be compliant with ICAO general rules of international air traffic and in accordance with their regulation for transport of troops, equipment, materials and dangerous goods, please write us for more detail information.

Required Details for Obtaining Egypt Overflight Permit Application


1 - Flight Schedule
2 - Entry / Exit Points with ATC Route
3 - Lead Passenger Details
4 - Consignee & Consigner Details for Cargo Flights
5 - Aircraft Documents [ AOC, COA, COI, CON, COR]

Overflight Permits Category’s for Adhoc and Private


1 - Overflight Permits (Charter Passenger Flights)
2 - Overflight Permits (Private Passenger Flights)
3 - Overflight Permits (Non-Schedule Cargo Flights)

Overflight Permits Category’s for Block :


1 - Monthly Block Overflight Permits (For Scheduled and Non-schedule Airlines Flights)
2 - Seasonal Block Overflight Permits (Scheduled Commercial Airlines Flights)

Permit Validity


- Egypt Overflight Permit is valid for +24 hours.

Overflight Permit Charge's


We do not charge any type of hidden cost in Civil Aviation Permit Processing Cost and Egypt Overflight Permits Procedures. Our fee is straight and direct without any additional fees in Egypt Overflight Permit We do not require large upfront deposits or commitments. We strive to develop long term relationships and we work hard to earn your referrals. Besides receiving essential financial monthly reports these very particular customers expect to entirely rely on professional teams and they offer just that. This trust is earned through our administrative and financial control, as well as our services standards of work.

Flight Information Region In Egypt


Egypt Airspace is divided into 01 Flight Information Regions (FIRs)

1 - Cairo (HECC) FIR


Egypt FIRs ( Entry / Exit Points ) :



West Bound Entry PointWest Bound Exit PointEast Bound Entry PointEast Bound Exit Point
NUBARNUBARRASDARASDA
 ATMULLAKTOLAKTO
DITARDITARPASOSPASOS
LOSULLOSULNALSONALSO
RAKMURAKMUMETSAMETSA
SALUNSALUNULINAULINA
METRUMETRUKITOTKITOT
TANSATANSAPASAM
PAXISPAXIS SILKA
ANTARANTAR IMRAD
KUMBIKUMBIGIBAL
  DEDLI
  ALEBAALEBA

International Trip Support Services


We provide comprehensive and personalized flight planning and International Trip Planning services to the corporate aviation industry. Our dedicated and experienced staff work together to ensure you have a smooth trip that is tailored to your particular needs. with years of international flight planning experience, the latest trip coordination technology, and a dedication to high-quality customer service, each member of our knowledgeable team is equipped with the tools to exceed your expectations.

Our proficient flight support team offering unrivalled support services to any International & Domestic Airports in Egypt along with their expertise, our permit2fly team can arrange Egypt Overflight Permits for Ad-hoc Charter Flights, Scheduled Airline Seasonal Block Permits from Civil Aviation Authority of Egypt according to their legal time frame.

Trust Permit2fly, to handle all your ground supervisory at Egypt airports and obtain Egypt overflight and Landing permit for any of your aircrafts to operate in the territory of Egypt.

About Egypt | History - Geography


Egypt, a country linking northeast Africa with the Middle East, dates to the time of the pharaohs. Millennia-old monuments sit along the fertile Nile River Valley, including Giza's colossal Pyramids and Great Sphinx as well as Luxor's hieroglyph-lined Karnak Temple and Valley of the Kings tombs. The capital, Cairo, is home to Ottoman landmarks like Muhammad Ali Mosque and the Egyptian Museum, a trove of antiquities.

Egypt has one of the longest histories of any country, tracing its heritage back to the 6th–4th millennia BCE. Considered a cradle of civilisation, Ancient Egypt saw some of the earliest developments of writing, agriculture, urbanisation, organised religion and central government.[14] Iconic monuments such as the Giza Necropolis and its Great Sphinx, as well the ruins of Memphis, Thebes, Karnak, and the Valley of the Kings, reflect this legacy and remain a significant focus of scientific and popular interest. Egypt's long and rich cultural heritage is an integral part of its national identity, which has endured, and often assimilated, various foreign influences, including Greek, Persian, Roman, Arab, Ottoman Turkish, and Nubian. Egypt was an early and important centre of Christianity, but was largely Islamised in the seventh century and remains a predominantly Muslim country, albeit with a significant Christian minority.

Egypt Overflight Permits Procedures

The Given Below Information Is Extracted from the Egypt AIP


Procedures For The Submission Of A Flight Plan

A flight plan shall be submitted prior to operating any flight.

Time Of Submission

Except for repetitive flight plans, A flight plan shall be submitted at least:

• 60 MIN prior to EOBT and not more than 120 hours prior to EOBT.

• 3 hours prior to EOBT and not more than 120 hours prior to EOBT for all flights destined or overflying restricted areas daily imposed by CFMU in the EUR region.

Note:On submitting such flight plans, requirements of ATS units in the airspace along the route to be flown for timely information ( including requirements for early submission for Air Traffic Flow Management purposes) are taken into account.

Place Of Submission

a) Flight plans shall be submitted to the Air Traffic Services Reporting Office (ARO) at the departure aerodrome (REF ENR 1.11)

b) in case of the absence of such an office, a flight plan shall be submitted to ATS unit at the departure aerodrome.

Contents and form of a flight plan a) ICAO flight plan forms are available at ARO, the instructions for completing those forms shall be followed.

Flight plans need to include FIR-boundary(s) estimates.

Adherence To The Published ATS Route Structure

No flight plans shall be filed for routes deviating from the published ATS route structure unless prior permission has been obtained from the appropriate authorities.

Authorization For Special Flights

Flights of specific character, such as survey flights, scientific research flights, etc..., may be exempted from the restriction specified in item 1.5 above. A request for exemption shall be mailed so as to be reached at least one week before the intended day of operation to the appropriate authorities.

Maximum cruising levels for short-range flights It is in generally recommended not to select levels above FL240 for flights up to a distance of 300 NM , Traffic from HELX to HECA via AWY A727 should file MAX FL240.

Repetitive Flight Plan System

The procedures concerning the use of Repetitive flight plans (RPL) conform to ICAO DOC 7030 (SUPPS) and the (DOC 4444) PANS-ATM,. RPL lists relating to flights in Cairo FIR shall be submitted at least two weeks in advance to RPL department by air mail or by hand to the following address.

National Air Navigation Services Company (NANSC)
Aeronautical Information Service (AIS), RPL department.
Cairo International Airport, Terminal 3, Cairo 11776, A.R.E.

RPL lists shall be replaced in their entirety by new lists at least 2 weeks prior to the introduction of the summer and winter schedules. RPL will not be accepted for any flight unless all ATS authorities concerned with the flight have agreed to accept it.

Incidental Changes And Cancellations Of RPL

Incidental changes to and cancellations of RPL departing from Egyptian aerodromes shall be notified as early as possible and not later than 60 minutes before departure to the (ARO) serving the departure aerodrome.

Delay

When a specific flight is likely to encounter a delay of 30 minutes or more in excess of the EOBT stated in the RPL, the ATS unit serving the departure aerodrome shall be notified immediately. Delays relating to departures from the Egyptian aerodromes shall be notified to the concerned ARO and the procedures mentioned in item 3 below shall be applied.

Note:Failure to comply with these procedures may result in the automatic cancellation of the RPL for that specific flight at one or more of the ATS units concerned.

ATS Messages

For a flight operating on an RPL, no flight plan (FPL) or Departure (DEP) messages relating to such flight will be transmitted to ATS units outside Cairo FIR.

Changes To The Submitted Flight Plan

All changes to a submitted flight plan shall be reported as soon as possible to the appropriate ATS unit.

In the event of a delay in departure, Except flights destined or overflying restricted areas daily imposed by CFMU in the EUR Region, 30 min delay after the approved EOBT is granted directly from the appropriate ATC unit, if the delay exceed 30 MIN a flight plan shall be amended or a new flight plan shall be submitted after the old flight plan has been cancelled.

Note:If a delay in departure of flight is not properly reported, the relevant flight plan data may no longer be readily available to the appropriate ATS unit when a clearance is ultimately requested, which will consequently result in extra delay for the flight.

Whenever a flight, for which a flight plan has been submitted, is cancelled, the appropriate ATS unit shall be informed immediately.

Changes to a valid flight plan during flight shall be reported or requested, according to the provisions in ICAO Annex 2 Item 3.6.2. (Adherence to flight plan).

Altimeter Setting Procedures
Introduction

The Altimeter Setting Procedures in use, generally conform to those contained in ICAO DOC. 8168- OPS/611 VOL 1 part 6, and are given in full below.

There are no differences.

Transition altitudes are given on the instrument approach charts.

QNH reports and temperature information for use in determining adequate terrain clearance is provided in MET and ATIS broadcasts, and is available on request from air traffic service units.

QNH are given in whole units.

Basic Altimeter Setting procedures
General

A transition altitude is specified for each aerodrome. No transition altitude is less than 900 meters (3000 feet) above an aerodrome.

Vertical positioning of aircraft when, at or below the transition altitude is expressed in terms of altitude whereas such positioning at or above the transition level is expressed in terms of flight levels.

While passing through the transition layer, vertical positioning is expressed in terms of altitudes when descending, and in terms of flight levels when ascending.

Flight level zero is located at the atmospheric pressure level of 1013.2 hpa (29.92insh). Consecutive flight levels are separated by a pressure interval corresponding to 500 feet (152.4M) in the Standard Atmosphere.

Take-Off And Climb

A QNH altimeter setting is made available to aircraft in taxi clearance prior to take-off.

Vertical positioning of aircraft during climb, is expressed in terms of altitudes until reaching the transition altitude, above which vertical positioning is expressed in terms of flight levels.

Vertical separation En-Route

Vertical separation during en-route flight shall be expressed in terms of flight levels at all times during an IFR Flight.

When complying with the cruising levels in Appendix 3 of Annex 2 an aircraft shall be flown at flight levels corresponding to the magnetic tracks.

Approach And Landing

A QNH altimeter setting is made available in approach clearances and in clearances to enter the traffic circuit.

Unlawful Interference

The following procedures are intended for use by aircraft when unlawful interference occurs and the aircraft is unable to notify an ATS unit of this fact.

Procedures

Unless considerations aboard the aircraft dictate otherwise, the pilot-in-command should attempt to continue flying on the assigned track and at the assigned cruising level at least until notification to an ATS unit is possible or the aircraft is within radar coverage.

When an aircraft subjected to an act of unlawful interference must depart from its assigned track or its assigned cruising level without being able to make radiotelephony contact with ATS, the pilot-in command should, whenever possible:

• Attempt to broadcast warnings on the VHF emergency frequency and other appropriate frequencies, unless considerations aboard the aircraft dictate otherwise. Other equipment such as onboard transponders, data links, etc. should also be used when it is advantageous to do so and circumstances permit.
