Thailand Overflight Permit Regulations

Delivery Aircraft Trip Support
Thailand Overflight Permits Procedures

International Trip Planning


Thailand country has its own set of rules, regulations and procedures for permits to aircraft wishing for landing or even entering their air space, whether you’re operating a private flight or general aviation, charter flight, scheduled or non-scheduled operation, passengers or cargo trip, a technical or traffic landing, Prior Permission is mandatory required the application procedures requiring complete flight information and Aircraft documents.

According to thailand civil aviation authority aeronautical information publication (or AIP) any aircraft owner/operator intent to fly in Thailand airspace request has to submit for Thailand overflight clearance to air transport department at least 48 working hours prior from flight departure schedule. Always include AFTN on your flight plan, but you’ll only need an overfly permit from Thailand.

Planning to make a passenger flight landing or technical stop, Thailand Airports Authority have their own regulations regarding the issuance of flight Thailand Overflight Permit as there is generally a payment involved. The charges normally payable would be the Route Navigation Facility Charges for overflight and also landing and parking charges in case of aircraft making halts.

Thailand is a signatory to the Chicago Convention therefore the conditions of flights and crews should strictly be compliant with ICAO general rules of international air traffic and in accordance with their regulation for transport of troops, equipment, materials and dangerous goods, please write us for more detail information.

Required Details for Obtaining Thailand Overflight Permit Application


1 - Flight Schedule
2 - Entry / Exit Points with ATC Route
3 - Lead Passenger Details
4 - Consignee & Consigner Details for Cargo Flights
5 - Aircraft Documents [ AOC, COA, COI, CON, COR]

Overflight Permits Category’s for Adhoc and Private


1 - Overflight Permits (Charter Passenger Flights)
2 - Overflight Permits (Private Passenger Flights)
3 - Overflight Permits (Non-Schedule Cargo Flights)

Overflight Permits Category’s for Block :


1 - Monthly Block Overflight Permits (For Scheduled and Non-schedule Airlines Flights)
2 - Seasonal Block Overflight Permits (Scheduled Commercial Airlines Flights)

Permit Validity


- Thailand Overflight Permit is valid for +24 hours.

Overflight Permit Charge's


We do not charge any type of hidden cost in Civil Aviation Permit Processing Cost and Thailand Overflight Permits Procedures. Our fee is straight and direct without any additional fees in Thailand Overflight Permit We do not require large upfront deposits or commitments. We strive to develop long term relationships and we work hard to earn your referrals. Besides receiving essential financial monthly reports these very particular customers expect to entirely rely on professional teams and they offer just that. This trust is earned through our administrative and financial control, as well as our services standards of work.

Flight Information Region In Thailand


Thailand Airspace is divided into 01 Flight Information Regions (FIRs)

1 - Bangkok (VTBB) FIR


Thailand FIRs ( Entry / Exit Points ) :



West Bound Entry PointWest Bound Exit PointEast Bound Entry PointEast Bound Exit Point
RUSETRUSETPONUKPONUK
SAPAMSAPAMTOMIPTOMIP
TAVUNTAVUNANBOKANBOK
IKULAIKULAATOGAATOGA
PADETPADETYAKUAYAKUA
EKAVOEKAVOBUTRABUTRA
AKATOAKATOBIDEMBIDEM
TANEKTANEKMENAMMENAM
LUDVILUDVIAGEDOAGEDO
MAKASMAKASBISOR BOKAK
BOMASBOMASSAKDA SAKDA
PUMOR BENSA BENSA
NURDA BASIT BASIT
SISUKSISUKTIDAR TIDAR
BETNOBETNODALAN DALAN
  DUBAX DUBAX
  RIGTO RIGTO
  TAMOS TAMOS
  KARMI KARMI
  PASVA PASVA
  GOLUD GOLUD
  NOLIC NOLIC
  KADAX KADAX
  ABTOK ABTOK

International Trip Support Services


We provide comprehensive and personalized flight planning and International Trip Planning services to the corporate aviation industry. Our dedicated and experienced staff work together to ensure you have a smooth trip that is tailored to your particular needs. with years of international flight planning experience, the latest trip coordination technology, and a dedication to high-quality customer service, each member of our knowledgeable team is equipped with the tools to exceed your expectations.

Our proficient flight support team offering unrivalled support services to any International & Domestic Airports in Thailand along with their expertise, our permit2fly team can arrange Thailand Overflight Permits for Ad-hoc Charter Flights, Scheduled Airline Seasonal Block Permits from Civil Aviation Authority of Thailand according to their legal time frame.

Trust Permit2fly, to handle all your ground supervisory at Thailand airports and obtain Thailand overflight and Landing permit for any of your aircrafts to operate in the territory of Thailand.

About Thailand | History - Geography


Thailand, country located in the centre of mainland Southeast Asia. Located wholly within the tropics, Thailand encompasses diverse ecosystems, including the hilly forested areas of the northern frontier, the fertile rice fields of the central plains, the broad plateau of the northeast, and the rugged coasts along the narrow southern peninsula.

Until the second half of the 20th century, Thailand was primarily an agricultural country, but since the 1960s increasing numbers of people have moved to Bangkok, the capital, and to other cities. Although the greater Bangkok metropolitan area remains the preeminent urban centre in the country, there are other sizable cities, such as Chiang Mai in the north, Nakhon Ratchasima (Khorat), Khon Kaen, and Udon Thani in the northeast, Pattaya in the southeast, and Hat Yai in the far south.

Thailand Overflight Permits Procedures

The Given Below Information Is Extracted from the Thailand AIP


Flight Planning

Flight plans must be submitted for international and domestic operations. The requirements of Flight plan are as follows:

Submission a Flight Plan

Civilian Aircraft - The flight plan shall be submitted to FDMC, ARO at the aerodrome of departure or designated ARO. During flight, transmitted to the appropriate air traffic services unit at the airport.

Military And Official Aircraft - The flight plan shall be submitted to Base Operations or ARO at the aerodrome of departure.

Aircraft departing from the aerodrome supervised by Airport of Thailand Public Company Limited, the flight plan shall be submitted to Aerodrome Aeronautical Information Services Unit at the airports.

Aircraft departing from the aerodrome supervised by Department of Airports, Ministry of Transport, the flight plan shall be submitted to ATC unit’s authority.

Aircraft departing from military aerodrome, the flight plan shall be submitted to Base Operations.

Aircraft departing from aerodrome other than 1, 2, 3, and 4 above, the flight plan shall be submitted to control tower of the nearest aerodrome.

The flight plan shall be submitted by pilot-in-command or designated representative, at least 1 hour prior to the estimated time of departure.

In the event of a delay of thirty (30) minutes in excess of the estimated off-block for a controlled flight or a delay of one-hour for an uncontrolled flight, the flight plan shall be automatically cancelled, unless the estimated time of departure is revised by notification of pilot-in-command or designated representative.

The pilot-in-command or designated representative shall use the ICAO flight plan form.

The international and domestic flight through intermediate stop(s) shall file separate flight plans for each state of flights at the aerodrome of first departure.

For Flights into areas for which ATFM measures have been established, Flight Plan shall be filed not later than 3 hours prior to the estimated off block time (EOBT).

The altitude of VFR flight departing aerodrome shall be given in field 15 of ICAO flight plan form.


AS THE COMPLIANCE TO THE USE OF MACH NUMBER TECHNIQUE TO REDUCE LONGITUDINAL SEPARATION TO 10 MINUTES BETWEEN TURBOJET AIRCRAFT USING INS OR VLF-OMEGA WHICH HAVE BEEN CERTIFIED AS MEETING THE OPERATE STANDARD SPECIFIED IN Z THE AUSTRALIAN MANUAL OF OPERATE STANDARD SECTION 1, AIRCRAFT MEETING THIS STANDARD SHALL INDICATE IN THE ICAO FPL FIELD 18 AS NAV/AUSEP. DUE TO THE IMPLEMENTATION OF THE FLIGHT DATA PROCEED SYSTEM AT BANGKOK ACC WHICH DOES NOT READ FIELD 18 OF THE ICAO FPL, THUS ALL AIRCRAFT ENTERING BANGKOK FIR/AOR ON ALL ROUTE SEGMENTS WHERE MACH NUMBER TECHNIQUE APPLIED ARE REQUESTED TO ADD “Z” AFTER COM/NAV EQUIPMENT IN FIELD 10 OF THE ICAO FPL IN ADDITION TO NAV/AUSEP IN FIELD 18.

Flight Data Management Centre (FDMC)

Flight Plans and flight plan associated message filed directly with FDMC will be checked by FDMC as regards syntax format and route structure. The route data outside the Bangkok FIR are not subject to verification. The originator will be informed of the successful processing of Flight plans and Flight plan associated message within FDMC by an Acknowledgement Message (“ACK” message). If not, they will be returned to the originator to be corrected receipt of the message (“REJ” Reject message).

The flight plan originator is responsible for:

1) Complete and correct data.

2) The originator will be informed of the successful processing of flight plan and flight plan associated messages within FDMC by an Acknowledgement Message (ACK message).

3) Checking Flight Plan ensure receipt of the message at FDMC Terminal. FDMC will be informed Acceptance Flight plan list.

Flight Plans, which cannot be processed by FDMC or not follow ICAO FPL format, will be returned to the originator to be corrected according to REJECT message (REJ) sending automatically from FDMC system.

Flight planning and operating procedure implemented in Bangkok FIR.

Implementation of uni-directional routes for flights operating in the south sectors of Bangkok FIR.

To enhance safety and efficiency of traffic flow in the south sectors of Bangkok FIR, For RNAV5 routes as follows:

• Y8 for southbound traffic to VTSP, VTSG, VTST, VTSB, VTSR, VTSE

• Y99 for northbound traffic to VTBD, BKK...

• Y96 for northbound traffic to VTBD

• Y98 for northbound traffic to VTBS

• Y17/W99 for northbound traffic from VTSM

• Y95 for traffic to or from VTSM (Bi-directional route)

Classification of Airspaces

Flight plans are only submitted to Flight Data Management Centre (FDMC) via AFTN address VTBBZPZX.

Flight movement messages relating to traffic into or via Bangkok FIR shall be addressed as stated below in order to warrant correct relay and delivery.

Flight movement messages in this context comprise flight plan messages, amendment messages relating thereto and flight cancellation messages ICAO PANS/ATM Doc 4444, Chapter 11,

Category Of Flight
(IFR, VFR or both)
Route - Into Or Via FIR and/or TMAMessage Address
123
All Flights (IFR/VFR)Into or via Bangkok FIR (VTBB)VTBBZQZX
All Flights (IFR/VFR)Outbound from aerodromes in Bangkok FIR (VTBB)VTBBZPZX
Addressing of Flight Plan Messages

ATS airspaces are classified and designated in accordance with the following:

Class A- IFR flights are permitted only, all flights are subject to Air Traffic Control service and are separated from each other.

Class B- IFR and VFR flights are permitted, all flights are subject to Air Traffic Control service and are separated from each other.

Class C- IFR and VFR flights are permitted, all flights are subject to Air Traffic Control service and IFR flights are separated from other IFR flights and from VFR flights. VFR flights are separated from IFR flights and receive traffic information in respect of other VFR flights.

Class D- IFR and VFR flights are permitted and all flights are subject to Air Traffic Control service, IFR flights are separated from other IFR flights and receive traffic information in respect of VFR flights, VFR flights receive traffic information in respect of all other flights.

Class E- IFR and VFR flights are permitted, IFR flights are subject to Air Traffic Control service and are separated from other IFR flights. ALL flights receive traffic information as far as practical.

Class F- IFR and VFR flights are permitted, all participating IFR flights receive an Air Traffic Advisory service and all flights receive flight information service if request.

Class G- IFR and VFR flights are permitted and receive flight information service if request.

Airspace classification is defined all ATS routes within Bangkok FIR are as follows:

• Class A from FL290 and above.

• Class B from FL280 and below.

Holding, Approach and Departure Procedures

The holding, approach and departure procedures in use are based on those contained in ICAO Doc 8168-OPS/611. (PANS-OPS).

Airspeeds listed are the maximum Indicated Airspeed (IAS) applicable at the designated holding altitudes and for aircraft types listed. Pilots are expected to hold at/or less than the specified airspeed when practicable.

LEVEL 1Normal ConditionsTurbulence Conditions
up to 14 000 feet inclusive170 knots (2) 230 knots (3)170 knots (2) 280 knots
above 14 000 feet to 20 000 feet inclusive240 knots (4)280 knots or 0.8 Mach whichever is less
above 20 000 feet to 34 000 feet inclusive265 knots (4)280 knots or 0.8 Mach whichever is less
above 34 000 feet0.83 Mach0.83 Mach
up to 14 000 feet inclusive170 knots (2) 230 knots (3)170 knots (2) 280 knots

1. The levels tabulated represent "altitudes" or corresponding "flight levels" depending upon the altimeter setting in use.

2. For holdings limited to category A and B aircraft only.

3. When the holding procedure is followed by the initial segment of an instrument approach procedure promulgated at a speed higher than 230 knots, the higher speed should also be used wherever possible.

4. Where possible, 280 knots should be use for holding procedures associated with airway route structures.

Arriving Flights

IFR flights entering and landing within a Terminal Control Area will be cleared to a specified holding point and instructed to contact Approach Control at a specified time, level or position. The terms of this clearance shall be adhered to until further instructions are received from Approach Control. If the clearance limit is reached before further instructions have been received, a holding procedure shall be carried out at the level last authorized.

Due to the limited airspace available, it is important that the approaches to the patterns and the holding procedures are carried out as exactly as possible. Pilots are strongly requested to inform ATC if, for any reason, the approach and/or holding cannot be performed as required.

Departing Flights

IFR flights departing from controlled aerodromes will initially receive ATC clearance from the local aerodrome control tower. The clearance limit will normally be the aerodrome of destination. IFR flights departing from non-controlled aerodromes will not take-off without prior arrangement with Bangkok Area Control Centre

Departure instructions are in accordance with ICAO Doc 4444 - ATM/501.
